DJI Mavic 2 Zoom

Sensor

1/2.3" CMOS
Effective Pixels: 12 million

Lens

FOV: about 83° (24 mm); about 48° (48 mm）
35 mm Format Equivalent: 24-48 mm
Aperture: f/2.8 (24 mm)–f/3.8 (48 mm)
Shooting Range: 0.5 m to ∞

ISO Range

Video:
100-3200
Photo:
100-1600 (auto)
100-3200 (manual)

Shutter Speed

Electronic Shutter: 8–1/8000s

Still Image Size

4000×3000

Still Photography Modes

Single shot
Burst shooting: 3/5/7 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
Interval (JPEG: 2/3/5/7/10/15/20/30/60s RAW:5/7/10/15/20/30/60s)

Video Resolution

4K: 3840×2160 24/25/30p
2.7K: 2688×1512 24/25/30/48/50/60p
FHD: 1920×1080 24/25/30/48/50/60/120p

Max Video Bitrate

100Mbps

Color Mode

D-Cinelike

Supported File System

FAT32 (≤ 32 GB)
exFAT (> 32 GB)

Photo Format

JPEG / DNG (RAW)

Video Format

MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)

Mechanical Range

Tilt: -135–45° Pan: -100–100°

Controllable Range

Tilt: -90–30° Pan: -75–75°

Stabilization

3-axis (tilt, roll, pan)

Max Control Speed (tilt)

120° /s

Angular Vibration Range

±0.01° (Mavic 2 Pro)
±0.005° (Mavic 2 Zoom)

Operating Frequency

2.400 - 2.483 GHz; 5.725 - 5.850 GHz

Max Transmission Distance (unobstructed, free of interference)

2.400 - 2.483 GHz; 5.725 - 5.850 GHz
FCC: 8000 m
CE: 5000 m
SRRC: 5000 m
MIC: 5000 m

Operating Temperature Range

0℃ - 40℃

Transmission Power (EIRP)

2.400 - 2.483 GHz
FCC: ≤26 dBm
CE: ≤20 dBm
SRRC: ≤20 dBm
MIC: ≤20 dBm
5.725-5.850 GHz
FCC: ≤26 dBm
CE: ≤14 dBm
SRRC: ≤26 dBm

Battery

3950 mAh

Operating Current/Voltage

1800 mA ⎓ 3.83 V

Supported Mobile Device Size

Max length: 160 mm; max thickness: 6.5–8.5 mm

Supported USB Port Types

Lightning, Micro USB (Type-B), USB-C

Capacity

3850 mAh

Voltage

15.4 V

Max Charging Voltage

17.6 V

Battery Type

LiPo 4S

Energy

59.29 Wh

Net Weight

297 g

Charging Temperature Range

5℃ - 40℃

Max Charging Power

80 W

Supported SD Cards

Micro SD™
Supporting Micro SD with capacity up to 128 GB and R/W speed up to UHS-I Speed Grade 3

Recommended microSD Cards

32G
Sandisk V30
Sandisk Extreme V30 Pro
64G
Sandisk Extreme Pro V30
128G
Sandisk Extreme V30
Sandisk Extreme Pro V30
Kingston

Takeoff Weight

Mavic 2 Pro: 907 g
Mavic 2 Zoom: 905g

Dimensions

Folded:
214×91×84 mm (length×width×height)
Unfolded:
322×242×84 mm (length×width×height)

Diagonal Distance

354 mm

Max Ascent Speed

5 m/s (S-mode)
4 m/s (P-mode)

Max Descent Speed

3 m/s (S-mode)
3 m/s (P-mode)

Max Speed (near sea level, no wind)

72 kph (S-mode)

Max Service Ceiling Above Sea Level

6000 m

Max Flight Time (no wind)

31 minutes (at a consistent 25 kph)

Max Hovering Time (no wind)

29 minutes

Max Flight Distance (no wind)

18 km (at a consistent 50 kph)

Max Wind Speed Resistance

29–38 kph

Max Tilt Angle

35° (S-mode, with remote controller) 25° (P-mode)

Max Angular Velocity

200°/s

Operating Temperature Range

-10°C - 40°C

Operating Frequency

2.400 - 2.483 GHz
5.725 - 5.850 GHz

Transmission Power (EIRP)

2.400 - 2.483 GHz
FCC：≤26 dBm
CE：≤20 dBm
SRRC：≤20 dBm
MIC：≤20 dBm
5.725-5.850 GHz
FCC：≤26 dBm
CE：≤14 dBm
SRRC：≤26 dBm

GNSS

GPS+GLONASS

Hovering Accuracy Range

Vertical:
± 0.1 m (when vision positioning is active)
± 0.5 m (with GPS positioning)
Horizontal:
± 0.3 m (when vision positioning is active)
± 1.5 m (with GPS positioning)

Internal Storage

8 GB

Sensing System

Omnidirectional Obstacle Sensing1

Forward

Precision Measurement Range: 0.5 - 20 m
Detectable Range: 20 - 40 m
Effective Sensing Speed: ≤ 14m/s
FOV: Horizontal: 40°, Vertical: 70°

Backward

Precision Measurement Range: 0.5 - 16 m
Detectable Range: 16 - 32 m
Effective Sensing Speed: ≤ 12m/s
FOV: Horizontal: 60°, Vertical: 77°

Upward

Precision Measurement Range: 0.1 - 8 m

Downward

Precision Measurement Range: 0.5 - 11 m
Detectable Range: 11 - 22 m

Sides

Precision Measurement Range: 0.5 - 10 m
Effective Sensing Speed: ≤ 8m/s
FOV: Horizontal: 80°, Vertical: 65°

Operating Environment

Forward, Backward and Sides:
Surface with clear pattern and adequate lighting (lux > 15)
Upward:
Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.)
Downward:
Surface with clear pattern and adequate lighting (lux > 15)
Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.)

Input

100-240 V, 50/60 Hz, 1.8A

Output

Main: 17.6 V ⎓ 3.41 A
or 17.0 V ⎓ 3.53 A USB: 5 V⎓2 A

Voltage

17.6 ± 0.1 V

Rated Power

60 W

Video Transmission System

OcuSync 2.0

Name

DJI GO 4

Live View Quality

Remote Controller:
720p@30fps / 1080p@30fps
DJI Goggles:
720p@30fps / 1080p@30fps DJI Goggles RE:
720p@30fps / 1080p@30fps

Latency (depending on environmental conditions and mobile device)

120 - 130 ms

Max Live View Bitrate

40Mbps

Required Operating System

iOS 9.0 or later Android 5.0 or later

Footnotes

[1] Omnidirectional Obstacle Sensing includes left/right, up/down, and forward/backward obstacle sensing. Sensing for left/right directions is only available in ActiveTrack or Tripod Mode. Omnidirectional Obstacle Sensing does not fully cover the circumference of a 360-degree arc. And left and right obstacle sensing system only works in specific modes and environments. DJI warranty does not cover any loss caused by crashing when flying left or right, even when ActiveTrack or Tripod mode is activated. Please be aware of your surroundings and App notifications when operating the Mavic 2 to ensure safety.

These specs have been determined through tests conducted with the latest firmware. Firmware updates can enhance performance, so updating to the latest firmware is highly recommended.
